| Back Side To Center Width | 1.14" |
| Bearing Insert Material | Alloy Steel |
| Bearing Insert Type | Radial Ball |
| Bearing Material Grade | 52100 |
| Bore Dia. | 2 1/4" |
| Bore Type | Cylindrical |
| Closure | Double Sealed |
| Dynamic Load Capacity | 11789 lbf. |
| Features | Available With High Temperature Bearings, Wide Inner Ring Bearing |
| Flange Thickness | 0.719" |
| Housing Material | Cast Iron |
| Housing Material Finish | Black Oxide |
| Housing Type | Square |
| Included Bearing | Uc212-36 |
| Includes | Set Screw |
| Lubricant Material Class | Nlgi #2 Equivalent |
| Lubrication Openings | One Zirc Fitting |
| Max. Speed | 3000 RPM |
| Max. Temp. | 220°F |
| Min. Temp. | -20°F |
| Mount Hole Center-to-center Height | 5 5/8" |
| Mount Hole Center-to-center Length | 5 5/8" |
| Mount Hole Size | 0.672" |
| Mounting Bolt Size | 5/8" |
| Number Of Mounting Holes | 4 |
| Overall Height | 6 7/8" |
| Overall Length | 6 7/8" |
| Overall Width | 2.562" |
| Rolling Element Rows | 1 |
| Seal Material | Felt |
| Seal Type | Contact |
| Self Lubricating Bearing | No |
| Shaft Locking Type | Set Screws |
| Static Radial Load Capacity | 8150 lbf. |
| Ship weight (kg) | 5.31 |
| Ship height (cm) | 17.46 |
| Ship length (cm) | 17.46 |
| Ship width (cm) | 6.51 |
