SEALMASTER ER-52 Insert Bearing, ER-52, 3 1/4 Inch Size Bore, 5 57/64 Inch Size OD | CU2KWM 44A689

SEALMASTER ER-52 Insert Bearing, ER-52, 3 1/4 Inch Size Bore, 5 57/64 Inch Size OD

Item: CU2KWM Model: ER-52Cross Ref: 44A689
See variants (14)
In Stock

Get it by Wednesday, Jan 1

£19.99 Flat Shipping + VAT £19.99 flat shipping is applicable on orders with an aggregate weight less than 10kg. Orders exceeding 10kg will be charged default shipping rates

£1,240.16 /unit (Inc. VAT)
Trade Prices Available
Add To Cart
Request a Quote

Payment Methods

Delivery Partners

How NET30 Works

Step 1 Add the items into your cart or submit a Purchase order

Step 2 Checkout, select NET30 payment (provide company registration and VAT number)

Step 3 Delivery via TNT or Royal Mail and receive invoice for payment in 30-days

Step 4 Make payment via BACS to our factoring partner,

Product Specifications:

Ball MaterialAlloy Steel
Ball Material Grade52100
Bearing Insert TypeRadial/Deep Groove Ball
Bore Dia.3 1/4"
Bore Dia. Tolerance-0.0015" to 0"
Cage MaterialBrass
ClosureDouble Sealed
Dynamic Radial Load Capacity18681 lbf.
Element MaterialAlloy Steel
Features120° Spacing Setscrew Lock With Diamond Faceted Setscrews, 360° Grease Circulation Around The Rolling Elements, Better Retained And Utilized Lubrication, Unique Land Riding Retainer Design Provides Superior Pocket Clearance, Use In Sealmaster Machined Housings Only
FinishBlack Oxide
For EnvironmentHighly Dusty And Dirty
IncludesRetaining Ring, Set Screws
Inner Ring Outside Dia.4.156"
Inner Ring Width3.38"
Insert ShapeCylindrical
Load DirectionRadial
Lubricant Material ClassNlgi #2 Equivalent
Lubrication OpeningsGrease Fitting
Max. Temp.220°F
Min. Temp.-20°F
Outer Ring Width1.938"
Outside Dia.5.891"
Ring End To Center Width2.031"
Ring MaterialAlloy Steel
Ring Material Grade52100
Rolling Element Material Grade52100
Rolling Element Rows1
Seal MaterialFelt
Seal TypeContact
Shaft Locking TypeSet Screws
Static Radial Load Capacity14496 lbf.

Shipping Info:

Ship weight (kg) 4.28
Ship height (cm)2.54
Ship length (cm)2.54
Ship width (cm)2.54

Product Variants

ProductModelPrice
SEALMASTER 2-34 Insert Bearing, 2-34, 3 1/4 Inch Size Bore, 5 57/64 Inch Size OD | CU2KWA 44A630
 2-34£1,729.96
SEALMASTER 2-38 Insert Bearing, 2-38, 3 1/2 Inch Size Bore, 6 19/64 Inch Size OD | CU2KWB 44A633
 2-38£1,874.94
SEALMASTER 3-111 Insert Bearing, 3-111, 1 11/16 Inch Size Bore, 3 17/32 Inch Size OD | CU2KWC 44A636
 3-111£284.10
SEALMASTER 3-33 Insert Bearing, 3-33, 3 3/16 Inch Size Bore, 5 57/64 Inch Size OD | CU2KWD 44A652
 3-33£1,454.66
SEALMASTER ER-16 Insert Bearing, ER-16, 1 Inch Size Bore, 2 3/64 Inch Size OD | CU2KWF 44A660
 ER-16£76.26
SEALMASTER ER-23 Insert Bearing, ER-23, 1 7/16 Inch Size Bore, 2 53/64 Inch Size OD | CU2KWG 44A667
 ER-23£125.34
SEALMASTER ER-24 Insert Bearing, ER-24, 1 1/2 Inch Size Bore, 3 9/64 Inch Size OD | CU2KWH 44A668
 ER-24£133.82
