| Item | Metric Motor |
| Bearings | Ball |
| Duty Cycle | Continuous |
| Frame | 100L |
| Frame Material | Cast Iron |
| Full Load Amps | 10.4/5.2A |
| Hp | 4 |
| Hz | 50/60 Hz |
| Inverter Rated | Yes |
| Length Less Shaft | 338 mm |
| Max. Ambient Temp. | 40 Deg. C |
| Motor Application | General Application |
| Motor Design | 3 phase |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Rotation | CW/CCW |
| Motor Thermal Protection | None |
| Nameplate Rpm | 1765 |
| Nema Design | N |
| Nominal Efficiency | 89.5% |
| Number Of Speeds | 1 |
| Overall Length | 398 mm |
| Phase | 3 |
| Service Factor | 1.15 |
| Shaft Dia. | 28mm |
| Shaft Length | 60 mm |
| Voltage | 230/460V AC |
| Warranty | 1 yr. |
| Ship weight (kg) | 46.64 |
| Ship height (cm) | 36.65 |
| Ship length (cm) | 43.19 |
| Ship width (cm) | 27.34 |
| Country of Origin | IN |
