| Item | General Purpose Motor |
| Bearings | Ball |
| Capacitor Required | No |
| Duty | Continuous |
| Efficiency | 77.1% |
| Efficiency Group | Standard |
| Frame | 184T |
| Frame Material | Rolled Steel |
| Full Load Amps | 28/14.6-14 |
| Hp | 3 |
| Hz | 60 |
| Insulation Class | F |
| Inverter Rated | No |
| Length Less Shaft | 12.125" |
| Max. Ambient Temp. | 40 Degrees C |
| Motor Application | General Application |
| Motor Design | Capacitor-Start |
| Motor Enclosure Design | Totally Enclosed Fan-Cooled |
| Motor Mounting Position | Horizontal |
| Motor Mounting Type | Rigid Base |
| Motor Shaft Design | Keyed |
| Motor Shaft Rotation | Clockwise, Counter Clockwise |
| Motor Thermal Protection | None |
| Mounting | Base |
| Nameplate Rpm | 1755 |
| Nominal Efficiency | 80% |
| Number Of Speeds | 1 |
| Overall Length | 14 15/16" |
| Phase | 1 |
| Rotation | CW/CCW |
| Rpm Group | 1701-1800 |
| Rpm Range | 1701-1800 |
| Service Factor | 1.00 |
| Shaft Dia. | 1.125" |
| Shaft Length | 2 13/16" |
| Voltage | 115/208-230 |
| Warranty | 1 Years |
| Ship weight (kg) | 32.4 |
| Ship height (cm) | 32.72 |
| Ship length (cm) | 45.57 |
| Ship width (cm) | 33.17 |
| HS code | 8501406040 |
| Country of Origin | MX |
| Product | Model | Frame | Full Load Amps | HP | Insulation Class | Length Less Shaft | Nameplate RPM | Nominal Efficiency | Overall Length | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
184TBFW7701 | 184T | 22-19.8 | 5 | F | 14.125" | 3530 | 82.5% | 16 15/16" | £1,494.95 | |
 |
184TBFW7726 | 184T | 21.5-19.5 | 5 | F | 14.625" | 1755 | 85.5% | 17.437" | £1,504.27 | |
 |
213TBFW7001 | 213T | 36-32-32 | 7.5 | F | 15.375" | 3465 | 81.5% | 18.75" | £1,708.58 | |
 |
213TBFW7026 | 213T | 24.5-22-22 | 5 | B | 15.375" | 1749 | 82.5% | 18.75" | £1,490.62 | |
 |
215TBFW7026 | 215T | 35-30-30 | 7.5 | B | 17 11/16" | 1740 | 84% | 21 1/16" | £1,270.21 | |
 |
215TBFW7027 | 215T | 41.5 | 10 | F | 17 11/16" | 1759 | 85.5% | 21 1/16" | £1,990.31 |
