| Item | Locking Connector |
| Amps | 20 |
| Antimicrobial | No |
| Cable Range | 0.350-1.150" |
| Color | Black, White |
| Connectivity | Pressure Terminal Screws |
| Cord Dia. Range | 0.350"-1.150" |
| Cord Size | 0.35 to 1.15" |
| Current Rating | 20 A |
| Diameter B-c-e | Pressure Terminal Screws |
| Dielectric Strength | Withstands 2,000V minimum |
| Grade | Industrial/Commercial |
| Height | 3.86" |
| Hp | 2 |
| Insulation | Insulated Body |
| Ip Rating | 20 |
| Length | 2.33" |
| Material | Nylon |
| Mounting | Cord Mounted |
| Nema Configuration | L18-20R |
| Nema Rating | L18-20R |
| Number Of Poles | 4 |
| Number Of Wires | 4-Wire |
| Operating Temp. | Maximum continuous 75 Deg. C and minimum-40 Deg. C without Impact |
| Phase | 3 Phase WYE |
| Type | Non-Shrouded |
| Voltage | 120/208 VAC |
| Voltage Rating | 3 Phase WYE 120/208 VAC |
| Width | 2.33" |
| Wire Size | #16 AWG to #8 AWG |
| Wire Type | Standard |
| Ship weight (kg) | 0.18 |
| Ship height (cm) | 9.8 |
| Ship length (cm) | 5.92 |
| Ship width (cm) | 5.92 |
| HS code | 8536694020 |
| Country of Origin | US |
| Product | Model | Amps | Cable Range | Color | Connectivity | Cord Size | Current Rating | Grade | Height | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
HBL4729CBK | 15 | - | Black | Pressure Terminal Screws | 0.23 to 0.72" | 15 A | Industrial/Commercial | 2.78" | £52.24 | |
 |
HBL2313BK | 20 | 0.360-0.930" | Black | Screw Terminals | 0.36 to 0.93" | 20 A | Industrial/Commercial | 3.86" | £58.14 | |
 |
HBL2613BK | 30 | 0.360-0.930" | Black | Pressure Terminal Screws | 0.36 to 0.93" | 30 A | Industrial/Commercial | 3.86" | £114.84 | |
 |
HBL2323BK | 20 | - | Black | Pressure Terminal Screws | 0.36 to 0.93" | 20 A | Industrial/Commercial | 3.86" | £58.14 | |
 |
HBL2623BK | 30 | - | Black | Pressure Terminal Screws | 0.36 to 0.93" | 30 A | Industrial/Commercial | 2.26" | £115.97 | |
 |
HBL2513BK | 20 | - | Black | Pressure Terminal Screws | 0.35 to 1.15" | 20 A | Industrial/Commercial | 2.33" | £124.30 | |
 |
HBL2813BK | 30 | - | Black | Pressure Terminal Screws | 0.35 to 1.15" | 30 A | Industrial/Commercial | 3.86" | £158.45 |
