| Item | Hydraulic Cylinder |
| Cylinder Effective Area Advance | 1.76 sq. in. |
| Cylinder Return Type | Single-Acting, Spring Return |
| Dimension A | 4.78" |
| Dimension B | 3.73" |
| Dimension C | 3.48" |
| Dimension C1 | 0.43" |
| Dimension D | 1 7/8"-16 UN |
| Dimension D1 | 1.79" |
| Dimension E | 0.78" |
| Dimension E1 | 0.75" |
| Dimension F | 1.63" |
| Dimension K | 1/2"-13 UNC |
| Dimension P | 0.31" |
| Dimension S | 0.67" |
| Dimension T | 0.47" |
| Material | Steel |
| Max. Cylinder Capacity Advance | 8800 lbs. |
| Max. Operating Pressure | 5000 psi |
| Oil Capacity Advance | 1.73 cu. in. |
| Plunger Type | Solid |
| Stroke | 1.05" |
| Ship weight (kg) | 1.04 |
| Ship height (cm) | 9.47 |
| Ship length (cm) | 4.76 |
| Ship width (cm) | 4.76 |
| HS code | 8412210030 |
| Country of Origin | US |
| Product | Model | Cylinder Effective Area Advance | Dimension A | Dimension B | Dimension C | Dimension C1 | Dimension D | Dimension D1 | Dimension E | Price | |
|---|---|---|---|---|---|---|---|---|---|---|---|
 |
CST271 | - | - | - | - | - | - | - | - | £132.64 | |
 |
CST2131 | - | - | - | - | - | - | - | - | £163.68 | |
 |
CST471 | - | - | - | - | - | - | - | - | £139.22 | |
 |
CST4131 | 0.2 sq. in. | 2.71" | 2.21" | 2.05" | 0.37" | 3/4"-16 UNF | 0.69" | 0.27" | £158.98 | |
 |
CST971 | 0.39 sq. in. | 2.54" | 2.26" | 2.03" | 0.32" | 1"-12 UNF | 0.88" | 0.39" | £215.41 | |
 |
CST9131 | 0.39 sq. in. | 3.02" | 2.5" | 2.28" | 0.32" | 1"-12 UNF | 0.88" | 0.39" | £190.02 | |
 |
CST9251 | 0.39 sq. in. | 4.46" | 3.42" | 3.21" | 0.32" | 1"-12 UNF | 0.88" | 0.39" | £200.36 |
