| Item | Sensor |
| Angle Measuring Range | 120 Deg. |
| Bearings | Ball Bearing |
| Connector Type | AMP Superseal 1.5 |
| Current Consumption | 10 mA |
| Housing Material | PBT |
| Ip Rating | Ip67 |
| Max. Operating Temp. | 85 Deg. C |
| Max. Operating Voltage | 30V DC |
| Max. Output Signal | 4.5V DC |
| Max. Radial | 100 N |
| Max. Shaft Load, Axial | 50 N |
| Max. Storage Temp. | 85 Deg. C |
| Mean Time To Failure | 133A |
| Min. Load Resistance | 20000 Ohm |
| Min. Operating Temp. | -40 Deg. C |
| Min. Operating Voltage | 10V DC |
| Min. Output Signal | 0.5V DC |
| Min. Storage Temp. | -40 Deg. C |
| Output | 1 |
| Output Signal Center Position/zero Position | 2.5V DC |
| Output Voltage | 0.5 to 4.5V |
| Resolution | 0.1 Deg. |
| Signal Sequence | Counter Clock Wise |
| Signal Update Rate | 2000 Hz |
| Technology | Hall |
| Temperature Coefficient | typ. - 250 ppm/K to typ. +250 ppm/K |
| Torque For Fastening Screws | 2.5 Nm |
| Typical Linearity Error | -5 Deg. to +5 Deg. |
| Model | Bearings | Housing Material | Max. Output Signal | Max. Radial | Max. Shaft Load, Axial | Min. Output Signal | Output | Output Signal Center Position/zero Position | Price | |
|---|---|---|---|---|---|---|---|---|---|---|
| 424A07A120B | Plain Bearing | Polybutylene Terephthalate | - | 1 N | 50 N, 0 N | - | - | 2.5V DC | - | RFQ
|
| 424A17A120 | Ball Bearing | PBT | 4.5V DC | 100 N | 50 N | 0.5V DC | 1 | 2.5V DC | - | RFQ
|
| 424A10A120B | Ball Bearing | PBT | 5V DC | - | 50 N | 1V DC | 1 to 5V | 3V DC | - | RFQ
|
| 424RA177P120B | - | - | - | - | - | - | - | - | - | RFQ
|
